20MPa 45MPa Stationary Hydrogen Storage Tank Group Assembly


Category:

Hydrogen Storage Modules


Product Details




Hydrogen storage tank hydrogen gas tank 20MPa 25Mpa 45Mpa hydrogen storage tube



Tank Dimension(OD*L)mm

φ559x11770

φ559x8976

φ485x7955

φ485x11728

Filling Medium

H2

H2

H2

H2

Working pressure(MPa)

20

25

45

45

Water capacity(m3)

2.35

1.7

1

1.5

Working temperature(°C)

-40~85

-40~85

-40~85

-40~85

Tank  weight(Kg)

3377

3119

3212

4759

1. The total volume of the stationary tank group can be determined by the combination of the number of tanks

   according to  customer requirements;

2. Station tank group classification method, can be customized according to customer needs.

Key words:

Hydrogen、Fuel cell、Application
